Technical Specifications
| S.NO. | DESCRIPTION | SIZES | MODEL NAME: BHPL-15"X12"-I | MODEL NAME: BHPL-18"X12"-II | MODEL NAME: BHPL-20"X12"-III |
| 1 | Charging Box | Inch | 50X15X20 | 52X18X20 | 52X20X20 |
| 2 | Pressed Bale | Inch | 15X12X T Var | 18X12X T Var | 20X12X T Var |
| 3 | Bale Weight | Kgs. | 25-30 | 35-40 | 45-50 |
| 4 | Electric Motor | H.P. | 15 | 20 | 20 |
| 5 | Idle Cycle | Seconds | 45 | 50 | 55 |
| 6 | Prod /shift | Tons | 4-5 | 5-6 | 6-7 |
| 7 | Oil Tank | Litters | 400 | 400 | 400 |
Highlights
[] Machine will be fabricated out of 50 mm thick M.S. Rolled Prime plates.
[] Pressured Bundle Ejection from front side (manually).
[] Single compact unit mounted over channel.
[] Limit valve & Check valve are provided for extended safety.
[] No civil foundation is required.
[] Excellent after-sale-service.
