Technical Specifications

S.NO.	DESCRIPTION	SIZES	MODEL NAME: BHPL-12"X22"-I	MODEL NAME: BHPL-24"X12"-II
1	Charging Box	Inch	22” x 22” x 52”	24X24X52
2	Pressed Bale	Inch	12”x22” x T(var)	24X12X T Var
3	Bale Weight	Kgs.	35-45 Kgs.	50-60
4	Electric Motor	H.P.	25 H.P	25
5	Idle Cycle	Seconds	60	60
6	Prod /shift	Tons	12	12-15
7	Oil Tank	Litters	400	450

Highlights
[] Machine will be fabricated out of 50 mm thick M.S. Rolled Prime plates.
[] Pressured Bundle Ejection from front side (manually).
[] Single compact unit mounted over channel.
[] Limit valve & Check valve are provided for extended safety.
[] No civil foundation is required.
[] Excellent after-sale-service.
