Technical Specifications

S.NO.	DESCRIPTION	SIZES	MODEL NAME: BHPL-8"X8"-I	MODEL NAME: BHPL-10"X10"-II	MODEL NAME: BHPL-12"X12"-III	MODEL NAME: BHPL-14"X14"-IV
1	Charging Box	Inch	52X18X20	55X18X20	55X20X22	55X24X24
2	Pressed Bale	Inch	8X8X T Var	10X10X T Var	12X12X T Var	14X14X T Var
3	Bale Weight	Kgs.	25-30	35-40	45-50	55-60
4	Electric Motor	H.P.	30	30	30	30
5	Idle Cycle	Seconds	60	60	65	70
6	Prod /shift	Tons	7-8	8-9	10-11	12-13
7	Oil Tank	Litters	700	700	700	700

Highlights
[] Machine will be fabricated out of 50 mm thick M.S. Rolled Prime plates.
[] Pressured Bundle Ejection from front side (manually).
[] Single compact unit mounted over channel.
[] Limit valve & Check valve are provided for extended safety.
[] No civil foundation is required.
[] Excellent after-sale-service.
